FL7031 – USB PD 3.0 Cable ID Controller (E-marker)
FL7031 is a USB PD 3.0 compliant controller for Type-C cables. This controller is a low pin count solution for Type-C Cable Electronic Marking. No internal or external MCU is necessary making this an optimal solution for cost-sensitive applications. An on-chip eFuse memory allows for customization without an external EEPROM.
- Small Packages: 2×2 DFN_8L
- Low BOM cost. No external components.
- Single 5V power supply
- Integrated LDO Regulator
- Low Power consumption
- Integrated eFuse for customization
- Write Protect feature on the eFuse
- In-Cable eFuse programming. Allow the ID to be set in final assembly.
- 0 Compliant
- Vconn from 2.7V to 5.5V
- Extended header support for PD messages
- Protocol updates
- eFuse can be programmed up to 2 times
- Manufacturing code for eFuse to allow for customer product tracking
- 20V protection on the CC pin
